Product Summary

The 88E3081-D0-RAF1 is a Gigabit Ethernet Transceiver.

Parametrics

88E3081-D0-RAF1 absolute maximum ratings: (1) Collector-Emitter Voltage: 40Vdc; (2) Collector-Base Voltage: 75Vdc; (3) Emitter-Base Voltage: 6.0Vdc; (4) Collector Current - Continuous: 600mAdc.

Features

88E3081-D0-RAF1 features: (1)Ultra small form factor with low pin count; (2)Integrated market-leading PHY and SERDES; (3)Triple-speed 10/100/1000BASE-T IEEE 802.3u compliant operation; (4)Ultra-deep RAM on-chip.

Diagrams

88E3081-D0-RAF1 block diagram
